Automactic Single End Chamfering Machine, China Factory Price
Tube processing machine

Automactic Single End Chamfering Machine

CJ-50 Double Row Chamfering Machine

The CJ-50 Double Row Chamfering Machine:
Ideal for Tube and Bar Single End Chamfering up to 50mm OD
Enhance your metalworking capabilities with the CJ-50 Chamfering Machine, expertly designed to handle tube and bar chamfering with an impressive capacity of up to 50mm OD. This robust machine is perfect for efficient single tube end chamfering, and also caters to solid bars, offering versatility and precision in your metalworking projects.

Features:
Ensures Clean Surfaces for Tube Welding
Accurate Angular Chamfers for Enhanced Fitting & Assembly
Comprehensive I/O Chamfering & Facing Or Boring for Precision
Smooth Radius Chamfering for Improved Finishing
Precise Centering & Outer Chamfer and Drilling for Solid Bars"

Paremeters

Model

CJ-50

Type

Hydraulic Drive

Pipe Diameter

10-50mm

Bar Diameter

6-25mm

Work Length

Standard material 100-400mm (2pcs); short material 70-400mm (2pcs)

Work accuracy

±0.1mm

Work Speed

3-5s/pcs

Machine Motor

2.2kw

Work Pressure

MPA 6-8KG

Weight

900kg

Dimension

260*100*120cm

Suit Material

Steel,Iron, Stainless Steel, Aluminum, Copper,Plastic,Nylon etc
